CNC Machining

WEC Machining Ltd offers a wide range of CNC machining and sheet metal services on a make-to-print basis. Utilising the latest machine tool technology, WEC Machining can produce individual components in batches of all sizes through to complex mechanical and electro-mechanical assemblies.

Recent investment has focused on machine tools offering reduced set-up times coupled with high throughputs providing our customers with value for money solutions. Additional investment in off-line programming and Inspection equipment enables WEC Machining to consistently produce high quality components and assemblies to meet the most exacting expectations.   Download our latest capacity list!

CNC Mill/Turn (up to 4m length, 920mm diameter)

Our investments in the latest Mazak Integrex enable us to machine complex parts in one hit

QTY Machine DIA LENGTH DRIVEN TOOLS
1 Mazak Integrex 300Y CNC Mill Turn Centre 500mm 900mm
1 Mazak Integrex 200 IVS 250mm 700mm

CNC Turning (Up to 3.8m Length)

Our CNC Turning Centres with both driven tooling and sub-spindle options provide Precision CNC Turning & Large CNC Turning Capacity up to 3.8 metres in length.

QTY Machine DIA LENGTH BAR FEED DRIVEN TOOLS
1 Hankook Fanuc CNC Turning Centre 950mm 3845mm
1 Mazak 350MY CNC Turning Centre 480mm 1583mm 85mm 12
1 Mazak Quickturn Smart 300M 420mm 1250mm   12
1 Mazak 200MS (sub-spindle) CNC Turning Centre 380mm 750mm 65mm 12
1 Doosan 280M 280mm 658mm 76mm 12
1 Mazak QT 15N CNC Lathe 150mm 250mm 50.8mm
1 Mazak Nexus 100 CNC Lathe 160mm 252mm 50.8mm YES
1 Mazak QT 200 MSY CNC Lathe 380mm 575mm 63.5mm YES
1 Mazak SQT 15M CNC Lathe 300mm 500mm 50.8mm YES
1 Mazak QT 20H-P CNC Lathe 440mm 429mm
1 Mazak QT30 CNC Lathe 300mm 1000mm
1 SQT15M CNC Lathe 300mm 500mm

Sliding Head Turning

Recent investments in the latest sliding head turning technology enables WEC Machining to produce a high volume of precision turned parts to the highest quality.

QTY Machine DIA Bar Feed
1 Citizen Miyano ABX64 SYY42 Sliding Head Lathe 64mm 3m
1 Citizen M32 7 axis Sliding Head Lathe 32mm 3m
1 Citizen L32 Viii Sliding Head Lathe 32mm 3m

CNC Milling

Continuing investment in the latest technology provides customers with a CNC Vertical Milling capability up to three metres in length together with CNC Horizontal Pallet loaders for cost-effective batch manufacturing

QTY Machine X Y Z
1 Correa Axia floor-type Milling Machines 11500mm 1500mm 2500mm + 450mm
1 Correa Axia floor-type Milling Machine 10000mm 1500mm 2000mm + 450mm
1 Asquith Butler Power Centre 500 8000mm 1500mm 2000
1 MTE BF-3200 Universal Milling Machine 3000mm 1250mm 1500mm
1 Mazak FJV 35/60 II 2240mm 880mm 650mm
1 HAAS VF-9/40 2134mm 1016mm 762mm
1 HAAS VF-6/40SS 1526mm 813mm 762mm
1 Mazak VT C 20 CNC Machining Centre 1660mm 510mm 640mm
1 HAAS VF-4SS 1270mm 508mm 635mm
1 HAAS VF-4 1270mm 508mm 635mm
1 Mazak HCN 5000 CNC Machining Centre Twin Pallet 500mm x 500mm 700mm 700mm 700mm
1 HAAS VF1 508mm 406mm 508mm

Vertical Machining Centres

  • High pressure through spindle coolant
  • High speed spindles for rapid removal of material and high surface finish
  • Renishaw infa red tool setting and part checking probes
  • 4th axis machining capability


QTY Make Model Spindle Tools X Y Z
1 HAAS VF-4SS 12000 24 1270mm 508mm 635mm
1 HAAS VF-6/40SS 12000 24 1526mm 813mm 762mm
1 HAAS VF-9/40 8100 24 2134mm 1016mm 762mm

Precision Grinding

WEC Machining have recently invested to acquire two Jones and Shipman Universal Grinders which now enables us to offer Subcontract Precision Grinding

QTY Machine DIA LENGTH
2 Jones and Shipman Universal Grinder 14" 40"

Conventional Machining

WEC Machining also benefits from a wide range of conventional machines which complements our CNC Machining section nicely.

QTY Machine DIMENSIONS
1 Parkson M1200 Horizontal Milling Machine 40" x 10" Table
1 Parkson M1200 Vertical Milling Machine 40" x 10" Table
1 Archdale Radial Drill 48" Swing
1 Bark Herbert Drills with Tapping Heads
1 Bridgeport Milling Machine 36" x 7" Table
1 Bridgeport Milling Machine with Slotting Head 36" x 7" Table
1 Surface Grinder 36" x 10" Table
